Medium Thick Metal Workpiece Precision Laser Cutting Machine

Working principle

The principle of laser work is that the gas or solid laser works to produce laser, and the parallel divergent laser beam is transmitted to the specified position through the fiber (or xenon lamp) and then focused to a very small focus through the lens, forming a high energy density spot. By adjusting the lens, the size and position of the focus can be changed to adapt it to different materials and cutting requirements. This precise focus control is the key to achieving high precision cutting. The laser beam is gathered into a small spot through the focusing mirror and projected onto the metal surface, and the focus reaches a high power density, when the material is irradiated the part is quickly heated to the vaporization temperature, evaporating to form a hole, with the light beam and the material moving relatively linearly, so that the hole continuously forms a narrow width slit, so as to achieve the purpose of cutting the material. During the cutting process, the nozzle ejects auxiliary gas from the direction parallel to the beam to blow away the slag to ensure the laser cutting quality. Driven by the servo motor, the cutting head moves according to the predetermined trajectory, thus cutting out various shapes of the workpiece.

Through the precise control of each component of the laser cutting machine, the CNC system realizes the dynamic adjustment of the cutting path, speed and focus, so that it can adapt to the workpiece of different shapes and sizes, and achieve three-dimensional precision cutting.

The 5-axis linkage 3D cutting pattern is not restricted

Positioning accuracy :±0.01mm

Cutting accuracy :±0.03mm

Repeatability :±0.01mm

Cutting speed :≤60m/min

Applicable material: Sheet metal/pipe/stretch/die casting

Advantages

1, high precision: laser cutting CNC precision, CNC software programming + servo motor drive, positioning accuracy of 0.03mm, repeated positioning accuracy of 0.02mm.

2, good cutting quality: no burr, no wrinkle, no slag: laser cutting head does not contact the material, to ensure that the workpiece is not scratched during the processing, no mechanical stress deformation.

3, fast speed: cutting speed can reach 18m/min, the maximum positioning speed can reach 110m/min, much faster than the wire cutting speed

4, save mold investment: laser processing does not require mold, no mold change time, reducing production costs.

5, not affected by the hardness of the material: the laser can be carbon steel, stainless steel, aluminum alloy, copper and other materials without deformation processing.

6, improve the speed of new product development: after the formation of product drawings, you can immediately carry out laser cutting, do not need to open, can be rapid production, not affected by the shape of the workpiece, speed up the progress of new product development.

7, save materials: the use of computer programming typesetting, can be different shapes of products size set cut, improve the utilization of materials, greatly reduce the cost of enterprise materials.
